HVAC & Refrigeration
The HVAC (Heating, Ventilation, and Air Conditioning) and refrigeration industry is vital for modern living, ensuring comfort, safety, and efficiency in homes, offices, factories, and cold‑chain logistics. Sheet metal fabrication plays a central role in producing ducts, ventilation panels, heat exchangers, and protective enclosures. These components must be manufactured with precision to guarantee proper airflow, energy efficiency, and long‑term durability. FormNCut machines provide the advanced technology needed to meet these requirements, combining speed, accuracy, and reliability for HVAC and refrigeration manufacturers worldwide.
Laser Cutting Machines in HVAC & Refrigeration
FormNCut Fiber Laser Cutting Machines are widely used to cut thin and thick sheets of galvanized steel, aluminium, and stainless steel for HVAC applications. Their ability to produce distortion‑free cuts makes them ideal for components that require exact dimensions and clean edges.
- Duct sheet cutting – Fiber lasers cut duct sheets to exact sizes, ensuring proper fitment during installation and reducing leakage.
- Ventilation panel cutting – Panels with intricate shapes, perforations, and holes are cut cleanly, supporting efficient airflow and modern designs.
- Heat exchanger plates – Thin sheets for exchangers are cut without thermal distortion, maintaining efficiency and performance.
Advantages of Laser Cutting Machines
- High precision ensures proper fit and sealing in ducts and panels
- Ability to cut complex perforations and shapes quickly
- Distortion‑free cutting improves efficiency of heat exchangers
- Faster production cycles compared to mechanical cutting methods
- Reduced need for secondary finishing, saving time and cost
Operational Process of Laser Cutting
- Sheet metal is loaded onto the cutting bed.
- CAD designs for ducts, panels, or exchangers are programmed into the CNC controller.
- The fiber laser beam is focused through collimating and focusing lenses.
- Assist gases (oxygen, nitrogen, or air) are regulated to achieve clean cuts.
- Height sensors maintain consistent distance between nozzle and sheet.
- Finished parts are unloaded, ready for assembly with minimal finishing.
Bending Machines in HVAC & Refrigeration
FormNCut CNC Press Brakes, including Hydraulic Servo Press Brakes and Panel Benders, are essential for bending sheet metal into ducts, frames, and enclosures. These machines ensure accurate angles and repeatable bends, which are critical for proper airflow and structural stability.
- Duct bending – Press brakes bend rectangular or square ducts with precise angles, ensuring proper sealing and airflow.
- AC frame bending – Air conditioner body frames are bent straight and repeatable, supporting reliable assembly.
- Cooling unit enclosure bending – Large covers for refrigeration units are bent accurately, protecting sensitive components.
Advantages of Bending Machines
- CNC control ensures precise angles and repeatable bends
- Strong, durable bends improve product safety and reliability
- Ability to bend both thin and thick sheets with equal accuracy
- Servo systems reduce energy consumption and improve efficiency
- Crowning systems compensate for deflection, ensuring uniform bends
Operational Process of Bending
- Sheet metal is positioned using back gauges and sensors.
- CNC controller programs the bending sequence for ducts or enclosures.
- Punch and die tooling apply force to bend the sheet into the required shape.
- Crowning systems adjust for deflection, ensuring uniform bends across the sheet.
- Servo motors deliver smooth, controlled movement for precise bending.
- Finished ducts, frames, or enclosures are inspected for accuracy before assembly.
Laser cutting ensures clean, distortion‑free edges, while bending machines form accurate ducts and housings. Together, they help manufacturers produce efficient, safe, and high‑quality HVAC and refrigeration products that meet modern industry standards.
